TP-Link ER707-M2 Omada 6 Port Multi-Gigabit VPN Router
TP-Link ER707-M2 Omada 6 Port Multi-Gigabit VPN Router
Dual-Core ARMv8, 1x 2.5Gb WAN, 1x 2.5Gb WAN/LAN, 1x Gigabit SFP WAN/LAN, 4x RJ45 WAN/LAN, Up to 6x WAN Ports, Highly Secure VPN, Omada SDN
Specifications
Access Control | Source/Destination IP Based Access Control |
Filtering | • WEB Group Filtering • URL Filtering • Web Security |
ARP Inspection | • Sending GARP Packets • ARP Scanning • IP-MAC Binding |
Attack Defence | • TCP/UDP/ICMP Flood Defense • Block TCP Scan (Stealth FIN/Xmas/Null) • Block Ping from WAN |
Standards and Protocols | • IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q, IEEE802.3bz • TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP, WireGuard VPN |
Interface | • 1× 2.5G RJ45 WAN Port • 1× 2.5G RJ45 WAN/LAN Port • 1× Gigabit SFP WAN/LAN Port • 4× Gigabit RJ45 WAN/LAN Ports • 1× USB 2.0 Port (Supports USB storage, and LTE backup with LTE dongle) |
Network Media | • 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) • 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m) • 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m) • 2500BASE-T: UTP category 5, 5e, 6 cable (Max 100 m) |
Fan Quantity | Fanless |
Button | Reset Button |
Power Supply | 12V/1.5A Adapter |
Flash | 128MB NAND |
DRAM | 1 GB DDR4 |
LED | PWR, SYS, SFP, USB, WAN (Speed, Link/Act), LAN (Speed, Link/Act) |
Dimensions (W x D x H) | 226 × 131 × 35 mm |
Protection | 4 kV surge protection |
Enclosure | Steel |
Mounting | Rackmout, Desktop, or Wall Mount |
Max Power Consumption | 14.2 W (with USB2.0 connected) 7.1 W (without USB2.0 connected) |
IPS Throughput | TCP: 208 Mbps; UDP: 161 Mbps |
DPI Throughput | TCP: 1823 Mbps; UDP: 1272 Mbps |
WireGuard VPN Throughput | 343Mbps |
Concurrent Session | 500,000 |
New Sessions / Second | 6,000 |
NAT (Static IP) | 2365.17 Mbps / 2364.45 Mbps |
NAT (DHCP) | 2364.45 Mbps / 2366.04 Mbps |
NAT (PPPoE) | 2347.14 Mbps / 2348.29 Mbps |
NAT (L2TP) | 1308.86 Mbps / 974.10 Mbps |
NAT (PPTP) | 1236.27 Mbps / 1280.99 Mbps |
IPsec VPN Throughput | • ESP-SHA1-AES256: 673.3 Mbps • ESP-SHA256-AES256: 650.2 Mbps • ESP-SHA384-AES256: 629.3 Mbps • ESP-SHA512-AES256: 633.8 Mbps |
L2TP VPN | • Unencrypted: 1243.7 Mbps • Encrypted: 561.0 Mbps |
SSL VPN Throughput | 132.24 Mbps |
66 Byte Packet forwarding rate | 1832.69 Mbps / 1741.84 Mbps |
1,518 Byte Packet forwarding rate | 2461.18 Mbps / 2457.32 Mbps |
WAN Connection Type | • IPv4_Static IP • IPv4_Dynamic IP • IPv4_PPPOE • IPv4_L2TP • IPv4_PPTP • IPv6_PPP • IPv6_DHCPv6 • IPv6_Static IP • IPv6_6in4 • IPv6_Pass-Through • Mobile Broadband: 4G/3G modem for backup via USB port |
MAC Clone | Modify WAN/LAN MAC Address |
DHCP | • DHCP Server • DHCPv6 PD Server (only in Standalone Mode) • DHCP Options Customization • DHCP Address Reservation • Multi-IP Interfaces • Multi-Net DHCP |
IPv6 | StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode |
VLAN | 802.1Q VLAN |
IPTV | IGMP v2/v3 Proxy, Custom Mode, Bridge Mode |
Operating Temperature | 0–40 ℃ |
Operating Humidity | 10–90% RH non-condensing |
TP-Link ER707-M2 Omada 6 Port Multi-Gigabit VPN Router
Description
The TP-Link ER707-M2 Omada 6 Port Multi-Gigabit VPN Router is a high-performance router designed to meet the needs of both home and business users who demand fast, secure, and reliable network connections. Featuring six multi-gigabit ports, this router delivers exceptional speed and versatility, making it ideal for high-bandwidth applications like streaming, gaming, and business network management.
With robust VPN capabilities, the ER707-M2 provides secure and private network access for remote users, offering peace of mind for businesses in New Zealand that need to protect sensitive data. Whether you're setting up a secure office network or a high-performance home setup, this router ensures optimal connectivity with support for up to 10Gbps of total bandwidth across its multi-gigabit ports.
Key Points
-
6 Multi-Gigabit Ports: Equipped with 6 high-speed Ethernet ports (including 2.5Gbps and 1Gbps options), the ER707-M2 allows
for superior connectivity for multiple devices simultaneously, ensuring fast data transfer without bottlenecks.
-
VPN Capabilities: Supports robust VPN protocols like IPsec and L2TP for secure, encrypted connections for remote users,
enhancing data privacy and security.
-
Omada Cloud Management: Manage your network remotely via the Omada Cloud platform, giving you full control over your router
from anywhere, at any time.
-
High-Speed Internet Performance: With up to 10Gbps total bandwidth, the ER707-M2 ensures smooth and lag-free internet
connectivity for high-demand activities like video conferencing, online gaming, and large file transfers.
-
Advanced Security Features: Includes built-in firewall protection, intrusion prevention systems, and content filtering,
helping safeguard your network from external threats and attacks.
-
Seamless Integration with Omada Ecosystem: The router integrates easily with TP-Link's Omada ecosystem, allowing you to
extend your network with Omada access points and switches for a unified management experience.
-
Easy Setup: The router comes with an intuitive setup process, making it easy for both home and business users to get up and
running quickly.
Benefits
-
High-Speed Performance: The TP-Link ER707-M2 offers multi-gigabit connectivity with speeds of up to 10Gbps across its 6
ports. This makes it perfect for both home and office networks that require fast internet speeds and seamless device communication.
-
Enhanced Security: With its VPN support and advanced security features, the ER707-M2 ensures your network is protected from
unauthorized access, making it an ideal choice for businesses in New Zealand that need secure remote access and data protection.
-
Centralized Network Management: Through the Omada Cloud platform, you can manage all your devices, monitor traffic, and
perform troubleshooting tasks remotely. This is a perfect solution for businesses that need centralized control over their network
infrastructure.
-
Multi-Device Support: With 6 ports, including 2.5Gbps connections, the router provides ample support for multiple
high-performance devices, ensuring there is no slowdown, even when several devices are connected at once.
-
Seamless Remote Access: The VPN capabilities of the ER707-M2 allow remote workers or employees to securely access their
corporate network, providing flexibility for New Zealand businesses that have a distributed workforce or need to enable secure
work-from-home setups.
-
Future-Proof Networking: The multi-gigabit ports and VPN capabilities make the ER707-M2 a future-proof choice for
businesses and home users looking to scale their network without needing to upgrade hardware as demands increase.
Why Choose This Product?
The TP-Link ER707-M2 Omada 6 Port Multi-Gigabit VPN Router stands out as a premium solution for users who require high-speed, secure, and scalable network connectivity. Whether you’re enhancing your home network for entertainment or setting up a professional-grade network for your business, this router delivers the performance and security you need. It is especially suited for New Zealand businesses that need remote worker capabilities, reliable data transfer, and centralized network management.
-
Fast and Reliable: Multi-gigabit speeds ensure your network runs at optimal levels even under high-demand conditions.
-
Secure VPN Access: The built-in VPN support allows businesses to provide remote access to employees, ensuring secure
connections and data privacy.
-
Cloud Management: Full control over your network with TP-Link’s Omada Cloud management system makes it easier to maintain
and optimize your network, whether at home or on the go.
The product may be provided by a different brand of comparable quality.
The actual product may vary slightly from the image shown.
